Contact manufacturer to confirm your lift includes ANSI updates.
For specs prior to ANSI updates click here
Engine | Power Option |
Electric |
Platform | Max Platform Height |
19 ft 3 in |
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
5'5" x 29.9" |
|
Dimensions | Overall Width |
30 in |
Turning Radius |
5 ft 1 in |
|
Wheelbase |
4 ft 4 in |
|
Overall Height Stowed |
7 ft 1 in |
|
Overall Length |
6 ft |
|
Ground Clearance |
3.20 in |
|
Operational | Operating Weight |
3,209 lbs |
Maximum Speed |
2.50 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
