Engine | Power Option |
Dual Fuel or Diesel |
Drive |
2WS or 4WS |
|
Platform | Max Platform Height |
66 ft 8 in |
Max Horizontal Reach |
56 ft 9 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' |
|
Dimensions | Overall Width |
98 in |
Turning Radius |
17 ft 7 in |
|
Overall Height Stowed |
8 ft 5 in |
|
Ground Clearance |
1 ft |
|
Overall Length |
35 ft 8 in |
|
Operational | Operating Weight |
26,650 lbs |
Maximum Speed |
4.25 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
