Platform | Max Platform Height |
180 ft |
Max Horizontal Reach |
80 ft |
|
Max Weight Capacity |
750 lbs |
|
Platform Rotation |
160 degree |
|
Platform Dimensions |
8' x 3' |
|
Dimensions | Overall Width |
98 in |
Turning Radius |
24 ft 1 in |
|
Wheelbase |
16 ft 6 in |
|
Overall Height Stowed |
10 ft |
|
Overall Length |
53 ft 1 in |
|
Ground Clearance |
1 ft 3 in |
|
Operational | Operating Weight |
55,000 lbs |
Maximum Speed |
2.50 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
