Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
10,000 lbs |
Max Lifting Height |
44 ft 3 in |
|
Operating Weight |
27,645 lbs |
|
Maximum Forward Reach |
29 ft 6 in |
|
Maximum Speed |
15 mph |
|
Lift Capacity at Maximum Reach |
1,800 lbs |
|
Draw Bar Pull |
20,000 lbs |
|
Lift Capacity at Maximum Height |
7,000 lbs |
|
Dimensions | Overall Width |
101 in |
Turning Radius |
147 in |
|
Overall Height Stowed |
8 ft 1 in |
|
Ground Clearance |
19 in |
|
Overall Length |
21 ft 2 in |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
