Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
10,000 lb |
Max Lifting Height |
55' 0" |
|
Operating Weight |
34,850 lb |
|
Draw Bar Pull |
24,000 lb |
|
Lift Capacity at Maximum Reach |
3,000 lb |
|
Maximum Speed |
20 mph |
|
Maximum Forward Reach |
42' 6" |
|
Lift Capacity at Maximum Height |
5,000 lb |
|
Dimensions | Overall Width |
8' 6" |
Turning Radius |
14' 6" |
|
Ground Clearance |
1' 7" |
|
Overall Length |
20' 0" |
|
Overall Height Stowed |
8' 6" |
|
Wheelbase |
12' 0" |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
