Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
10,000 lbs |
Max Lifting Height |
55 ft |
|
Operating Weight |
31,559 lbs |
|
Draw Bar Pull |
25,400 lbs |
|
Lift Capacity at Maximum Height |
5,000 lbs |
|
Maximum Forward Reach |
42 ft |
|
Maximum Speed |
20 mph |
|
Lift Capacity at Maximum Reach |
3,000 lbs |
|
Maximum Speed Field to Remain |
20 mph |
|
Dimensions | Overall Width |
101 in |
Turning Radius |
14 ft |
|
Wheelbase |
11 ft 6 in |
|
Overall Height Stowed |
8 ft 4 in |
|
Overall Length |
20 ft 1 in |
|
Ground Clearance |
1 ft 6 in |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
