Snorkel MB20J Specs
Articulating Boom Lift Specifications
| Engine | Power Option |
Electric |
| Platform | Max Platform Height |
20 ft |
| Max Horizontal Reach |
8 ft 6 in |
|
| Max Weight Capacity |
425 lbs |
|
| Platform Dimensions |
30" x 28" |
|
| Dimensions | Overall Width |
31 in |
| Turning Radius |
6 ft |
|
| Overall Length |
7 ft 11 in |
|
| Overall Height Stowed |
6 ft 6 in |
|
| Ground Clearance |
4 in |
|
| Operational | Operating Weight |
6,675 lbs |
| Maximum Speed |
2 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
