Engine | Power Option |
Electric |
Platform | Max Platform Height |
29 ft 9 in |
Max Horizontal Reach |
20 ft 6 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
46" x 30" |
|
Platform Rotation |
180 degree |
|
Dimensions | Overall Width |
47 in |
Turning Radius |
127 in |
|
Wheelbase |
5 ft 5 in |
|
Overall Height Stowed |
6 ft 7 in |
|
Overall Length |
17 ft 11 in |
|
Ground Clearance |
4 in |
|
Operational | Operating Weight |
12,265 lbs |
Maximum Speed |
3 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
