Contact manufacturer to confirm your lift includes ANSI updates.
For specs prior to ANSI updates click here
Engine | Power Option |
Dual Fuel or Diesel |
Platform | Max Platform Height |
40 ft |
Max Horizontal Reach |
33 ft 6 in |
|
Max Weight Capacity |
600 lbs unrestricted |
|
Platform Dimensions |
8' x 3' |
|
Max Weight Capacity* |
1,000 lbs restricted |
|
Dimensions | Overall Width |
91 in |
Ground Clearance |
1 ft |
|
Overall Length |
24 ft 10 in |
|
Turning Radius |
15 ft 8 in |
|
Overall Height Stowed |
8 ft 1 in |
|
Operational | Operating Weight |
14,520 lbs |
Maximum Speed |
4.50 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
