Genie S-40 XC Specs ANSI updated

Telescopic Boom Lift Specifications

Contact manufacturer to confirm your lift includes ANSI updates.

For specs prior to ANSI updates click here

Engine Power Option Diesel
Platform Max Platform Height 39 ft 6 in
Max Horizontal Reach 31 ft 1 in
Max Weight Capacity 660 lbs unrestricted
Max Weight Capacity* 1,000 lbs restricted
Platform Dimensions 8' x 3' or 6' x 2'6"
Platform Rotation 160 degree
Dimensions Overall Width 98 in
Turning Radius 17 ft 2 in
Wheelbase 8 ft
Overall Height Stowed 8 ft 3 in
Overall Length 26 ft 4 in
Ground Clearance 12 in
Operational Operating Weight 14,124 lbs
Maximum Speed 4 mph

Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
