Engine | Power Option |
Diesel |
Platform | Max Platform Height |
82 ft |
Max Horizontal Reach |
72 ft 6 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' |
|
Platform Rotation |
170 degree |
|
Dimensions | Overall Width |
98 in |
Turning Radius |
280 in |
|
Wheelbase |
11 ft |
|
Overall Height Stowed |
9 ft 10 in |
|
Overall Length |
37 ft 10 in |
|
Ground Clearance |
16 in |
|
Operational | Operating Weight |
37,150 lbs |
Maximum Speed |
3.50 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
