JLG 800S Specs
Telescopic Boom Lift Specifications
| Engine | Power Option |
Dual Fuel |
| Platform | Max Platform Height |
80 ft |
| Max Horizontal Reach |
71 ft |
|
| Max Weight Capacity |
500 lbs |
|
| Platform Dimensions |
8' x 3' |
|
| Dimensions | Overall Width |
98 in |
| Overall Height Stowed |
9 ft 11 in |
|
| Ground Clearance |
1 ft |
|
| Overall Length |
37 ft 3 in |
|
| Turning Radius |
22 ft 6 in |
|
| Operational | Operating Weight |
33,200 lbs |
| Maximum Speed |
3.50 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
