Engine | Power Option |
Diesel |
Platform | Max Platform Height |
185 ft 7 in |
Max Horizontal Reach |
80 ft |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' |
|
Dimensions | Overall Width |
98 in |
Turning Radius |
31 ft 3 in |
|
Ground Clearance |
1 ft 4 in |
|
Overall Length |
63 ft 10 in |
|
Overall Height Stowed |
10 ft |
|
Operational | Operating Weight |
60,300 lbs |
Maximum Speed |
2.80 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
