Engine | Power Option |
Dual Fuel or Diesel |
Drive |
2WD or 4WD |
|
Platform | Max Platform Height |
80 ft |
Max Horizontal Reach |
71 ft 6 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' or 6' x 2'6" |
|
Platform Rotation |
160 degree |
|
Dimensions | Overall Width |
98 in |
Turning Radius |
21 ft 6 in |
|
Overall Height Stowed |
9 ft 2 in |
|
Overall Length |
36 ft 6 in |
|
Ground Clearance |
15.80 in |
|
Wheelbase |
9 ft 4 in |
|
Operational | Operating Weight |
35,400 lbs |
Maximum Speed |
3.30 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
