Engine | Power Option |
Dual Fuel |
Drive |
2WD or 4WD |
|
Platform | Max Platform Height |
60 ft |
Max Horizontal Reach |
50 ft 10 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' or 6' x 2'6" |
|
Platform Rotation |
160 degree |
|
Dimensions | Overall Width |
98 in |
Overall Height Stowed |
8 ft 11 in |
|
Overall Length |
27 ft 9 in |
|
Ground Clearance |
1 ft 2.5 in |
|
Turning Radius |
18 ft 2 in |
|
Wheelbase |
8 ft 3 in |
|
Operational | Operating Weight |
20,570 lbs |
Maximum Speed |
4 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
