Genie S-40 TraX Specs
Telescopic Boom Lift Specifications
| Engine | Power Option |
Diesel DualFuel |
| Platform | Max Platform Height |
40' 0" |
| Max Horizontal Reach |
31' 8" |
|
| Max Weight Capacity |
660 lb |
|
| Platform Dimensions |
8' 0" x3' 0" 6' 0" x 2' 6" |
|
| Platform Rotation |
160 deg |
|
| Dimensions | Overall Width |
8' 2" |
| Turning Radius |
17' 0" |
|
| Ground Clearance |
12.5" |
|
| Overall Length |
26' 4" |
|
| Overall Height Stowed |
8' 5" |
|
| Wheelbase |
8' 1" |
|
| Operational | Operating Weight |
15,054 lb |
| Maximum Speed |
2.5 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
