Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
8,000 lbs |
Max Lifting Height |
41' 11" |
|
Operating Weight |
27,100 lbs |
|
Draw Bar Pull |
25,000 lbs |
|
Lift Capacity at Maximum Height |
6,000 lbs |
|
Maximum Forward Reach |
26' 7" |
|
Maximum Speed |
19 mph |
|
Lift Capacity at Maximum Reach |
2,200 lbs |
|
Dimensions | Overall Width |
8' 3" |
Turning Radius |
13' 0" |
|
Wheelbase |
10' 0" |
|
Overall Height Stowed |
8' 3" |
|
Overall Length |
19' 0" |
|
Ground Clearance |
1' 6" |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
