Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
20,000 lbs |
Max Lifting Height |
44 ft 10 in |
|
Operating Weight |
45,000 lbs |
|
Lift Capacity at Maximum Height |
12,000 lbs |
|
Maximum Forward Reach |
27 ft 5 in |
|
Maximum Speed |
20.50 mph |
|
Lift Capacity at Maximum Reach |
7,000 lbs |
|
Maximum Speed Field to Remain |
20.50 mph |
|
Dimensions | Overall Width |
102 in |
Turning Radius |
18 ft 4 in |
|
Overall Height Stowed |
9 ft |
|
Ground Clearance |
18 in |
|
Overall Length |
20 ft 3 in |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
