Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
6,000 lbs |
Max Lifting Height |
43 ft 4 in |
|
Operating Weight |
19,640 lbs |
|
Draw Bar Pull |
17,750 lbs |
|
Maximum Speed |
17 mph |
|
Maximum Forward Reach |
28 ft 7 in |
|
Lift Capacity at Maximum Reach |
1,000 lbs |
|
Dimensions | Overall Width |
101 in |
Turning Radius |
147 in |
|
Overall Height Stowed |
7 ft 11 in |
|
Ground Clearance |
19 in |
|
Overall Length |
19 ft 6 in |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
