Engine | Power Option |
Diesel |
Operational | Max Lifting Capacity |
6,600 lbs |
Max Lifting Height |
42 ft 1 in |
|
Operating Weight |
20,890 lbs |
|
Draw Bar Pull |
20,000 lbs |
|
Lift Capacity at Maximum Height |
6,000 lbs |
|
Maximum Forward Reach |
30 ft |
|
Maximum Speed |
23 mph |
|
Lift Capacity at Maximum Reach |
1,000 lbs |
|
Maximum Speed Field to Remain |
23 mph |
|
Dimensions | Overall Width |
99 in |
Turning Radius |
11 ft 9 in |
|
Overall Height Stowed |
7 ft 11 in |
|
Overall Length |
17 ft 9 in |
|
Ground Clearance |
1 ft 5 in |
|
Overall Length Stowed |
17 ft 9 in |
|
Wheelbase |
10 ft 8 in |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
