Engine | Power Option |
Diesel |
Platform | Max Platform Height |
85 ft |
Max Horizontal Reach |
56 ft |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' |
|
Platform Rotation |
170 degree |
|
Dimensions | Overall Width |
98 in |
Turning Radius |
20 ft 5 in |
|
Wheelbase |
9 ft 4 in |
|
Overall Height Stowed |
8 ft 9 in |
|
Overall Length |
38 ft 2 in |
|
Ground Clearance |
13 in |
|
Operational | Operating Weight |
37,400 lbs |
Maximum Speed |
3 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
