JLG M400AJPN Specs
Articulating Boom Lift Specifications
| Engine | Power Option |
Bi-Energy |
| Platform | Max Platform Height |
40 ft |
| Max Horizontal Reach |
30 ft 9 in |
|
| Max Weight Capacity |
500 lbs |
|
| Platform Dimensions |
4' x 2' |
|
| Dimensions | Overall Width |
59 in |
| Turning Radius |
10 ft 4 in |
|
| Ground Clearance |
5 in |
|
| Overall Length |
22 ft |
|
| Overall Height Stowed |
6 ft 6 in |
|
| Operational | Operating Weight |
15,200 lbs |
| Maximum Speed |
3 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
