Engine | Power Option |
Electric |
Platform | Max Platform Height |
45 ft |
Max Horizontal Reach |
23 ft 9 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
5' x 2' |
|
Dimensions | Overall Width |
69 in |
Overall Length |
21 ft 2 in |
|
Turning Radius |
10 ft 4 in |
|
Overall Height Stowed |
6 ft 7 in |
|
Ground Clearance |
9 in |
|
Operational | Operating Weight |
14,400 lbs |
Maximum Speed |
3.20 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
