Engine | Power Option |
Dual Fuel |
Platform | Max Platform Height |
60 ft 7 in |
Max Horizontal Reach |
39 ft 9 in |
|
Max Weight Capacity |
500 lbs |
|
Platform Dimensions |
8' x 3' |
|
Dimensions | Overall Width |
84 in |
Turning Radius |
11 ft 2 in |
|
Overall Height Stowed |
8 ft 4 in |
|
Ground Clearance |
1 ft |
|
Overall Length |
29 ft |
|
Operational | Operating Weight |
24,200 lbs |
Maximum Speed |
4.25 mph |
|
Lift specifications are from manufacturers websites.
Contact the manufacturer with serial number to confirm specification accuracy.
